ALC (Autoclaved Lightweight Concrete) Panel is a sustainable green building material for practical and straightforward construction. These panels make cement, lime, gypsum, and aluminum additives that help create bubbles within, making the panel lighter and thermally efficient.
The tongue and groove of these panels make the joint more secure and tight in terms of water leakage and, with its lightness in weight, makes the installation easier and faster.
Properties such as strength, acoustic, density, fire resistance, and eco-friendliness are strong points of the Ecotrend Panels. The material's customization and lightweight thickness allow for installing a wall faster, saving time and overall structural construction cost. The ALC material's unique properties, such as thermal insulative strength, will enable it to reduce energy wastages from elements such as cooling of a room.
Thickness/mm | 75 | 100 | 125 | 150 | 175 | 200 |
Intensity of Pressure(N/m2) | Maximal Length (mm) | |||||
800 | 2000 | 3000 | 3500 | 4200 | 4800 | 5200 |
1000 | 2000 | 3000 | 3500 | 4200 | 4800 | 5200 |
1200 | 1960 | 2920 | 3400 | 4080 | 4640 | 5200 |
1400 | 1920 | 2840 | 3300 | 3960 | 4480 | 5200 |
1600 | 1880 | 2760 | 3200 | 3840 | 4320 | 4950 |
1800 | 1840 | 2680 | 3100 | 3720 | 4160 | 4900 |
2000 | 1800 | 2600 | 3000 | 3600 | 4000 | 4800 |
2200 | ------ | 2500 | 2850 | 3350 | 3750 | 4700 |
