AUTOCLAVED AERATED CONCRETE BLOCK (ECOTREND AAC BLOCK)

Home / Products / AAC Block
Description of Product :
The technical performance and quality standard of ECOTREND’s block meet the requirements of the national autoclaved aerated concrete block GB11968-2006 standard. It is suitable for civil and industrial buildings in areas with seismic fortification intensity less than 7 degrees, which are made of non bearing wall materials by dry thin layer masonry technology; it is suitable for heat preservation and energy saving buildings, which are widely used in residential buildings, office buildings, hospitals, hotels, schools and other civil, public and industrial buildings.

Features of Product :
High strength, small density, light weight, easy to handle and transport, convenient secondary processing, good fire resistance, corrosion resistance, heat insulation and other properties;
COST-SAVING BENEFITS

1. Building Structure

The density of AAC is 1/3 of clay brick, which can reduce foundation cost 15-20%.


2. Installation Speed

The AAC block is about 4 times the size of brick, less joints and less mortar consumption, labor output is double than that of clay brick.

3. Energy Efficiency

The thermal conductivity of AAC is 1/4 of clay brick, helping keep indoors warm in winter and cool in summer, saving air-conditioning energy of up to 30%.
SAFETY BENEFITS

1. Fire-resistance

100mm thick wall has 4 hours of fire rating, recognized as Euro class A1 non-combustible product.


2. Anti-seismic

Lightweight and excellent integrity makes it able to absorb strong impacts, which reduced inertia force during the earthquake.


3. Non-toxic

No harmful gases will be released even at high temperature.


ECOTREND AAC BLOCK PERFORMANCE INDEX

Item

Technical performance index

Density

B04

B05

B06

Intensity level

A2.0

A2.5

A2.5

A3.5

A3.5

A5.0

Cube compressive strength (MPA)

Average value

≥ 2.0

≥ 2.5

≥ 2.6

≥ 3.5

≥ 3.6

≥ 5.1

Single block minimum value

≥ 1.6

≥ 2.0

≥ 2.1

≥ 2.8

≥ 3.0

≥ 4.1

Average dry density (kg/m3)

≤ 425

≤ 525

≤ 625

Dry thermal conductivity (w/(m·K))

0.11

0.13

0.14~0.15

Frost resistance index

Quality loss (%)

≤ 5.0

Post freezing strength

More than 80% of the average cube compressive strength

Drying shrinkage (mm/M)

≤ 0.5

ECOTREND AAC BLOCK PRODUCT MODEL

Serial number

Product name

Specification L × B × H (mm)

Level

1

External wall insulation block (customized products)

600×30×200

B04A2.0

2

600×40×200

B04A2.0

3

600×50×200

B04A2.0

4

600×240×200

B04A2.0

5

Internal / external wall conventional block (standing products)

600×100×200

B05A2.5

6

600×120×200

B05A2.5

7

600×150×200

B05A2.5

8

600×180×200

B05A2.5

9

600×200×200

B05A2.5

10

600×240×200

B05A2.5

11

600×100×200

B06A3.5

12

600×120×200

B06A3.5

13

600×150×200

B06A3.5

14

600×180×200

B06A3.5

15

600×200×200

B06A3.5

16

600×240×200

B06A3.5

17

Internal / external wall reinforced block (customized products)

600×100×200

B05A3.5

18

600×120×200

B05A3.5

19

600×150×200

B05A3.5

20

600×180×200

B05A3.5

21

600×200×200

B05A3.5

22

600×240×200

B05A3.5

23

600×100×200

B06A5.0

24

600×120×200

B06A5.0

25

600×150×200

B06A5.0

26

600×180×200

B06A5.0

27

600×200×200

B06A5.0

28

600×240×200

B06A5.0
